VI-4 UT

Max Static Load : 2200kg
Gear Ratio : 1/40
Power Range (kw) : 3,3.7
Brake Voltage (D.C) : 110 ,220
Sheave Range (mm) : 510,530
Oil Capacity ( Ltr ) : 2.5 (Approx)
Weight of Machine ( Kg ) : 220 (Approx)

Learn More
slider image

VI-5BT

Max Static Load : 3000kg
Gear Ratio : 1/40
Power Range (kw) : 3,3.7, 4.5
Brake Voltage (D.C) : 110 ,220
Sheave Range (mm) : 510, 530, 560
Oil Capacity ( Ltr ) : 2.75 (Approx)
Weight of Machine ( Kg ) : 285 (Approx)

Learn More
slider image

VI-5.5 UT

Max Static Load : 3800kg
Gear Ratio : 1/40,1/42
Power Range (kw) : 4.5,5.5,6.7
Brake Voltage (D.C) : 48, 60, 110 ,220
Sheave Range (mm) : 510, 530, 560, 610
Oil Capacity ( Ltr ) : 3 (Approx)
Weight of Machine ( Kg ) : 300 (Approx)

Learn More
slider image

VI-5 UT

Max Static Load : 3000kg
Gear Ratio : 1/40
Power Range (kw) : 3,3.7,4.5
Brake Voltage (D.C) : 110 ,220
Sheave Range (mm) : 510, 530, 560
Oil Capacity ( Ltr ) : 2.75 (Approx)
Weight of Machine ( Kg ) : 270 (Approx)

Learn More
slider image

VI-6 UT

Max Static Load : 4500kg
Gear Ratio : 1/40, 1/42, 1/50
Power Range (kw) : 5.5,6.7,7.5,9.2,11.00
Brake Voltage (D.C) : 48, 60, 110 ,220
Sheave Range (mm) : 560, 610, 660
Oil Capacity ( Ltr ) : 3.7 (Approx)
Weight of Machine ( Kg ) : 420 (Without bed plate)

Learn More
slider image

VI-5R, 6R, 7R, 8R, 9R

ARE AVAILABLE IN
[0.32,0.50,0.65,1.00 M/SEC]

Learn More
slider image

DUMBWAITER

Passenger Capacity (Kg) : 150 to 700 Kg
Gear Ratio : 1/40, 1/42
Brake Voltage (D.C) : 110 ,220
Oil Capacity ( Ltr ) : 2 .75 Ltr. (Approx)
Weight of Machine ( Kg ) : 250 to 300 Kg

Learn More
slider image

Company Profile

Since-1995

service box

Relationship

Varsha Industries was envisaged, promoted and incorporated by Mr. Dineshbhai Panchal in Ahmedabad in the year 1995. The company was well planned and established to manufacture prime quality Elevator Traction Machine.

service box

Vision

An entrepreneurship which is a committed organization with a sincere endeavour, with a foresight of vision and earnest passion to rise and serve, excel and grow, perform and prove.

service box

Target

Driven by the passion to create world-class entity for itself, the company has an environment that encourages the best potential management which incorporates the best technology

Products

"From PerfectTechnologyTo QualityProducts"

project

VI-4 UT (-115)

Client
DateMarch 7, 2015
CategoriesUPPER TRACTION UNIT
Link

Max Static Load : 2200kg
Gear Ratio : 1/40
Power Range (kw) : 3,3.7
Brake Voltage (D.C) : 110 ,220
Sheave Range (mm) : 510,530
Oil Capacity ( Ltr ) : 2.5 (Approx)
Weight of Machine ( Kg ) : 220 (Approx)

project

VI-5 BT (-127)

Client
DateMarch 7, 2015
CategoriesBOTTOM TRACTION UNIT
Link

Max Static Load : 3000kg
Gear Ratio : 1/40
Power Range (kw) : 3,3.7, 4.7
Brake Voltage (D.C) : 110 ,220
Sheave Range (mm) : 510, 530, 560
Oil Capacity ( Ltr ) : 2.75 (Approx)
Weight of Machine ( Kg ) : 285 (Approx)

project

VI-5.5 UT (-140)

Client
DateMarch 7, 2015
CategoriesUPPER TRACTION UNIT
Link

Max Static Load : 3800kg
Gear Ratio : 1/40,1/42
Power Range (kw) : 4.5,5.5,6.7
Brake Voltage (D.C) : 48, 60, 110 ,220
Sheave Range (mm) : 510, 530, 560, 610
Oil Capacity ( Ltr ) : 3 (Approx)
Weight of Machine ( Kg ) : 300 (Approx)

project

VI-5 UT (-127)

Client
DateMarch 7, 2015
CategoriesUPPER TRACTION UNIT
Link

Max Static Load : 3000kg
Gear Ratio : 1/40
Power Range (kw) : 3,3.7,4.5
Brake Voltage (D.C) : 110 ,220
Sheave Range (mm) : 510, 530, 560
Oil Capacity ( Ltr ) : 2.75 (Approx)
Weight of Machine ( Kg ) : 270 (Approx)

project

VI-6 UT (-152)

Client
DateMarch 7, 2015
CategoriesUPPER TRACTION UNIT
Link

Max Static Load : 4500kg
Gear Ratio : 1/40, 1/42, 1/50
Power Range (kw) : 5.5, 6.7, 7.5, 9.2, 11.00
Brake Voltage (D.C) : 48, 60, 110 ,220
Sheave Range (mm) : 560, 610, 660
Oil Capacity ( Ltr ) : 3.7 (Approx)
Weight of Machine ( Kg ) : 420 (Without Bed Plate)

project

DUMBWAITER

Client
DateMarch 5, 2015
CategoriesUPPER TRACTION UNIT
Link

Passenger Capacity (Kg) : 150 to 700 Kg
Gear Ratio : 1/40, 1/42
Brake Voltage (D.C) : 110 ,220
Oil Capacity ( Ltr ) : 2 .75 Ltr. (Approx)
Weight of Machine ( Kg ) : 250 to 300 Kg

Varsha Dumb Waiter Elevator Units are designed and manufactured for goods transportation from one floor to another successfully utilized to increase service
through decreased cost by reducing distance between people.

Varsha Dumb Waiter Unit is the perfect choice for any lift 50 feet or less. It is capable of speed of 0.3m/s. with load carrying capacity 150Kg to 750Kg.

It is suited for moving a variety of times from laundry in a hotel to food and dishes in restaurants, school, churches and clubs from lifting heavy files and office
supplies in banks, offices and labs to maintenance equipment in factories.

project

VI-5R, 6R, 7R, 8R, 9R.

Client
DateFebruary 18, 2015
CategoriesUPPER TRACTION UNIT
Link

ARE AVAILABLE IN
[0.32,0.50,0.65,1.00 M/SEC]

TECHNICAL CHART
technical chart

  • project

    VI-4 UT (-115)

    UPPER TRACTION UNIT

  • project

    VI-5 BT (-127)

    BOTTOM TRACTION UNIT

  • project

    VI-5.5 UT (-140)

    UPPER TRACTION UNIT

  • project

    VI-5 UT (-127)

    UPPER TRACTION UNIT

  • project

    VI-6 UT (-152)

    UPPER TRACTION UNIT

  • project

    DUMBWAITER

    UPPER TRACTION UNIT

  • project

    VI-5R, 6R, 7R, 8R, 9R.

    UPPER TRACTION UNIT

About us



Varsha Industries, The group whose name is synonymous with innovation and engineering excellence, was incorporated & envisaged by the professional founder incorporated & envisaged by the professional founder directions with rich experience and technology savvy background & qualifications. The company was founded in the year since 1995 for the manufacture of prime quality XiaomiElevator Traction Machines, with a keen focus on superior service and customer based engineering and technical solutions.

Lubrication

  • Shell

  • Indian Oil

  • Gulf

  • Castrol

OIL CHANGE

For mineral oil after about 350 operation hours ;

for synthetic oil after about 700 operation hours.

For mineral oils every 12/18 months ;

synthetic oils every 24/36 months depending on intensity of use

Use ISO - VG - 320 Grade of oil in Gear

Change mineral oil Every 12 / 18 months

For synthetic oils every 24 / 36 months depending

on the intensity of use
